Part no.: 79 5207 00 05
M12 Twin distributors, Y-distributor, male connector - 2 female connector, Contacts: 5/4, unshielded, pluggable, IP68, UL 2238
series 765, Automation Technology - Sensors and Actuators
3D View(Click to activate)
General features
Moreless| Part no. | 79 5207 00 05 |
| Connector design | Twin distributors, Y-distributor, male connector - 2 female connector |
| Type standard | DIN EN 61076-2-101 |
| Coding | A-coded |
| Version | Twin distributors |
| Connector locking system | screw |
| Termination | pluggable |
| Degree of protection | IP68 |
| Temperature range from/to | -25 °C / 85 °C |
| Mechanical operation | > 100 Mating cycles |
| Weight (g) | 27.00 |
| Customs tariff number | 85444290 |
| Country of Origin | DE |
Electrical parameters
Moreless| Rated voltage | 250 V |
| Rated impulse voltage | 2500 V |
| Rated current | 4.0 A |
| Pollution degree | 3 |
| Overvoltage category | II |
| Insulating material group | II |
| EMC compliance | unshielded |
Material
Moreless| Housing material | PUR |
| Contact body material | PUR |
| Contact material | CuZn (brass) / CuSn (bronze) |
| Contact plating | Au (gold) |
| Locking material | Zinc die-cast nickel-plated |
| REACH SVHC |
CAS 7439-92-1 (Lead) |
| SCIP number | 429d6db8-1b47-4790-8d51-58a63d0b48ca |
Authorization/approvals
Moreless| Approvals | UL 2238 |
Classifications
Moreless| eCl@ss 11.1 | 27-06-03-11 |
| ETIM 9.0 | EC002638 |
Declarations of conformity
Moreless| Low Voltage Directive | 2014/35/EU (EN 60529:1991 | 2014/35/EU;EN 60204-1:2018) |
