Power connectors
Filter products
Connector type
The connector type can be used to distinguish our products for installation in a device housing from cable parts. The connector type describes the difference between connectors that are mounted on enclosures, connectors that are mounted on cables, and other connection componentsdistributing signal and power.
Gender
A connector consists of the male part (pin) and the female part (socket). Depending on the design, the male or female part is either permanently installed or are located at the end of a cable.
Number of contacts
This indicates the number of contacts the connector has.
Version
The choice of version allows the definition of the cable outgoing.
Locking Type
The locking system describes how the pin and socket elements are joined.
Rated voltage
The rated voltage is the electrical voltage assigned to the connector.
Rated current
The rated current is the electrical current that is assigned to the connector.
Degree of protection
The degrees of protection according to IEC60529 apply to various articles and provide information on protection against the intrusion of water and solids such as dust.
Shielded Option
Electromagnetic compatibility (EMC) means that a connector is shielded or shieldable. This is required when it is necessary to protect the signals or data conducted by the connector, as well as to protect external devices, from disturbance due to electromagnetic effects.
Material of housing
Depending on the area of application or requirements, connectors are made of different materials. We offer metal and plastic housings for our items as the housing material.
Termination
The termination type determines how cables, single wires or PCBs can be joined with the connector.
Approval
Our articles have various approvals which can be preselected here. can be preselected here.
Locking material
Depending on the technical requirements or performance data of the connector, the locking mechanism is made of plastic or metal.
Single wire length
The stranded wire is an electrical conductor consisting of thin individual wires and is therefore easy to bend. The individual wires of the stranded wire are usually enclosed in a common insulating sheath and come in different wire lengths.
Mounting orientation
The mounting orientation for flange connectors defines the side from which an item can be mounted.
Mounting thread
There are different thread sizes for the device-side connection, depending on the design. These are available in different variants.
Cross section
The connection cross-section defines the possible size of a stranded wire on a contact in the flange or field attachable connector. Cross-sections from 0.08mm² to 6.0mm² are possible here. Since various industry are also using wires according to the American Wire Gauge (AWG), both units are reflected.
Cable outlet
Field attachable connectors can be assembled with different cables. The cable aperture indicates the possible cable diameters that can be used on an article.

The PBC15 connectors of the 615 series are especially suitable for power supply for motors and devices and also offer the possibility of electromagnetic shielding. They are standardised according to DIN EN IEC 61076-2-116 and are protected to IP67.
The cable connectors with quick locking and screwclamp terminal connection technology are particularly quick and easy to put into operation. In addition to the three power contacts with up to 16 A and 630 V, the connector has additional signal contacts with up to 10 A and 63 V, making it ideal for implementing single-cable solutions.
