  4. M16 IP67 - hex nut; series 423/425/723
Part no.: 01 5006 001

M16 IP67 - hex nut; series 423/425/723

series 423/425/723, Accessories
Compare product
General features
Part no. 01 5006 001
Thread M18x0.75
Width across flat SW 20
Weight (g) 4.133
Customs tariff number 85389099
Country of Origin DE
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number e5093b63-b58e-4078-aae7-423ef0644dfb
Surface DIN 50696 - Cu/Ni4 halbmatt
Material CuZn40 Pb3
eCl@ss 11.1 27-44-01-92
Security notices
  1. The connector must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury.
  2. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  3. Connectors which are used in circuits with voltages dangerous to the touch may only be installed and used by, or under the supervision of, persons with electrical engineering training, taking into account the applicable regulations and standards.
  4. The user must take suitable safety precautions to ensure that the connector cannot be accidentally disconnected.
  5. Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
  6. The plug connector is not suitable for mains voltages Please observe the pollution degree and the overvoltage category. For further information, please refer to the download center "Technical Information".
  7. To lock the cable connector with the device connector, the threaded ring is tightened "hand-tight" (approx. 60 cNm).
