General features
Moreless| Part no. | 01 1188 001 |
| Connector design | Nuts |
| Thread | M8x1,0 |
| Width across flat | SW 10 |
| Weight (g) | 0.83 |
| Customs tariff number | 85389040 |
| Country of Origin | CH |
Material
Moreless| REACH SVHC |
CAS 7439-92-1 (Lead) |
| SCIP number | 5b323f46-f43f-4a84-8f85-5106e05cc7af |
| Surface | DIN 50968-Cu/Ni4 halbmatt |
| Material | CuZn39Pb3 |
Classifications
Moreless| eCl@ss 11.1 | 27-44-01-92 |
Security notices
- The user must take suitable safety precautions to ensure that the connector cannot be accidentally disconnected.
