Bayonet NCC connectors Medical Grade
The robust plastic housing, combined with the simple bayonet locking mechanism, enables a fast and secure connection. The connection is made via solder or dip-solder terminals with a cross-section of 0.25 mm². These NCC< connectors are suitable for temperatures ranging from -25°C to +85°C.
NCC Connectors
The Medical Grade version of the 770 series is grey-white (similar to RAL 9002) and DEHP-free. These NCC connectors provide IP67 protection both when mated and unmated. Featuring eight gold-plated contacts and a rated current of 2A, these bayonet connectors are suitable for cable outlets with diameters of 2.5 - 4 mm, 4 - 6 mm, and 6 - 8 mm. They also offer a lifespan of over 5,000 mating cycles.
NCC connectors are the optimal solution for applications where reliability and safety are critical. The high quality of our bayonet connectors ensures the suitability of the products for use in Medical Grade applications. Protective caps for cable connectors as well as angled versions are also available upon request.
